| Nama merek: | SUNCAR |
| Nomor Model: | 31Y1-20910 HYUNDAI R360LC-7, R360LC-7A, R370LC-7 |
| MOQ: | Pesanan percobaan dapat diterima |
| harga: | Bisa dinegosiasikan |
| Detail Kemasan: | Tas PP di dalam, kotak karton di luar |
| Ketentuan Pembayaran: | Western Union, L/C, T/T, , D/A, D/P |
31Y1-20910 31Y120910 Boom Cylinder Repair Seal Kit Untuk R360LC-7 R370LC-7 Hyundai Alat Berat
| Nama Produk | Kit Segel Perbaikan Silinder Boom |
| Nomor Bagian | 31Y1-20910, 31Y120910 |
| Model | EXCAVATOR PERANGKAT SERI 7 R360LC-7, R360LC-7A, R370LC-7 |
| Bahan | PU, Karet, PTFE, NBR, HNBR, ACM, VMQ |
| Tempat asal | Cina (Daratan) |
| Nama merk | SUNCAR |
| Sedang mengemas | Tas PP di dalam, kotak karton di luar |
| Modus Pengiriman | Melalui udara, laut, ekspres (FedEx, UPS, DHL, TNT, dll.) |
| Syarat pembayaran | Western Union, Paypal, T/T, Transfer |
| Sertifikasi | ISO9001 |
| Jaminan | Tidak tersedia |
| Disesuaikan | OEM & ODM disambut |
| Grup Kategori | Kit segel silinder hidraulik, kit layanan ekskavator |
| Kondisi | Baru, asli baru |
| Sampel | Tersedia |
| Industri yang Berlaku |
Toko bahan bangunan, bengkel mesin, retail, Ada Pekerjaan Konstruksi... |
| Fitur | Kinerja penyegelan tinggi / ketahanan aus |
| Aplikasi | Ledakan |
Acara Produk:
Bagian Terkait:
| pos. | Bagian No | QTY | Nama Produk |
| *. | 31NA-50111 | [1] | BOOM CYLINDER-RH(1") |
| *. | 31NA-50112 | [1] | BOOM CYLINDER-RH |
| *. | 31NA-50113 | [1] | SILINDER ASSEMBLY,RH |
| *. | 31NA-50121 | [1] | BOOM CYLINDER-LH(1") |
| *. | 31NA-50122 | [1] | BOOM CYLINDER-LH |
| *. | 31NA-50123 | [1] | SILINDER ASSEMBLY, LH |
| 1 | 31Y1-20810 | [1] | ASSY TABUNG |
| 2 | 31Y1-20850 | [1] | ROD ASSY |
| 3 | 31Y1-20880 | [1] | KELENJAR |
| 4 | S732-110045 | [1] | BOS |
| 5 | Y191-117000 | [1] | RING-SNAP |
| K6. | Y220-110011 | [1] | SEAL-ROD |
| K7. | Y180-110020 | [1] | RING-BACK UP |
| K8. | Y240-110013 | [1] | RING-BUFFER |
| K9. | Y110-110011 | [1] | WIPER-DEBU |
| 10 | Y190-126000 | [1] | RING-SNAP |
| K11. | S631-150004 | [1] | O-RING |
| K12. | S641-150003 | [1] | RING-BACK UP |
| 13 | 31YC-23050 | [1] | BANTAL CINCIN |
| 14 | 31Y1-08172 | [1] | PISTON |
| K15. | S632-095004 | [1] | O-RING |
| K16. | S642-095003 | [2] | RING-BACK UP |
| K17. | Y420-160000 | [1] | SEAL-PISTON |
| K18. | Y310-160200 | [2] | PAKAI CINCIN |
| K19. | Y440-160000 | [2] | RING-DEBU |
| 20 | 31YC-66081 | [1] | WASHER-LOCK |
| 21 | 31YC-61143 | [1] | KUNCI-KACANG |
| 22 | S109-200904 | [12] | BOLT-SOCKET |
| 28 | 31YC-11205 | [1] | PIN BUSHING |
| 29 | 31YC-11405 | [1] | PIN BUSHING |
| 30 | Y000-110100 | [2] | SEAL-DEBU |
| 31 | Y000-100100 | [2] | SEAL-DEBU |
| 23 | 31Y1-08481 | [1] | BAND ASSY |
| 23 | 31Y1-22590 | [1] | BAND ASSY |
| 23 | 31Y1-22591 | [1] | BAND ASSY |
| 23-1. | 31Y1-08491 | [1] | BAND SUB ASSY |
| 23-1. | 31Y1-22600 | [1] | BAND SUB ASSEMBLY |
| 23-2. | 31YC-32120 | [1] | PITA |
| 23-3. | S015-120452 | [4] | BOLT-HEX |
| 23-4. | S411-120002 | [4] | WASHER-SPRING |
| 23-5. | 31YC-39010 | [1] | CLAMP-PIPE |
| 23-5. | 31YC-39030 | [1] | CLAMP-PIPE |
| 23-6. | S015-140852 | [1] | KEPALA BAUT-HEXAGON |
| 23-6. | S015-161002 | [1] | KEPALA BAUT-HEXAGON |
| 23-7. | S205-141002 | [1] | KEPALA HEXAGON NUT |
| 23-7. | S205-161002 | [1] | KEPALA HEXAGON NUT |
| 23-8. | S411-140002 | [1] | WASHER-SPRING |
| 23-8. | S411-140002 | [1] | WASHER-SPRING |
| 24 | 31Y1-20900 | [1] | PIPA ASSY-R,RH |
| 24 | 31Y1-22620 | [1] | PIPA ASSY-R,RH |
| 24 | 31Y1-22621 | [1] | PIPA ASSY-R,RH |
| 24 | 31Y1-22622 | [1] | PIPA ASSY-R,RH |
| 24 | 31Y1-20890 | [1] | PIPA ASSY-R,LH |
| 24 | 31Y1-22610 | [1] | PIPA ASSY-R,LH |
| 24 | 31Y1-22611 | [1] | PIPA ASSY-R,LH |
| 24 | 31Y1-22612 | [1] | PIPA ASSY-R,LH |
| 25 | 31Y1-18910 | [1] | PIPA ASSY-B,RH |
| 25 | 31Y1-22640 | [1] | PIPA ASSY-B,RH |
| 25 | 31Y1-22641 | [1] | PIPA ASSY-B,RH |
| 25 | 31Y1-22642 | [1] | PIPA ASSY-B,RH |
| 25 | 31Y1-18900 | [1] | PIPA ASSY-B,LH |
| 25 | 31Y1-22630 | [1] | PIPA ASSY-B,LH |
| 25 | 31Y1-22631 | [1] | PIPA-ASSY-B,LH |
| 25 | 31Y1-22632 | [2] | PIPA ASSY-B,LH |
| K26. | Y171-024004 | [2] | O-RING |
| 27 | S107-120554 | [8] | BOLT-SOCKET |
| 27 | S107-120604 | [8] | BOLT-SOCKET |
| 27 | S107-120554 | [8] | BOLT-SOCKET |
| K | 31Y1-20910 | [1] | SEAL KIT |
Pengingat hangat:
Bagian dijual dengan nomor bagian saja.Mesin atau mesin Anda mungkin memerlukan nomor suku cadang yang berbeda.Jika menurut Anda ini adalah bagian yang benar tetapi nomor bagian yang diiklankan berbeda dari yang Anda pikir Anda butuhkan, atau Anda tidak yakin dengan nomor bagian yang benar, silakan hubungi kami untuk mengonfirmasi kompatibilitas.Gagal memverifikasi kompatibilitas dapat mengakibatkan pengembalian, biaya penyetokan ulang yang signifikan, dan uang yang terbuang untuk pengiriman.
|
|
